Processor |
- Supports SMP (Symmetrical Multi-Processor) dual processors
- MPS (Multi-Processor Specification) rev 1.4 compliant
- Supports Intel Xeon processor with 512K cache up to 3.2GHz
- Supports FSB 533MHz |
Chipset |
- Intel E7501 memory controller hub (Plumas 533)
- Intel 82801DB IO controller hub (ICH3-S)
- Intel 82870P2 64bit PCI-X Bridge (P64H2)
- Supports PC2100 DDR Memory (ECC Registered DIMM)
- Supports dual peer to peer PCI/PCI-X buses
- Supports 64bit/66MHz PCI bus & 133MHz PCI-X bus |
System Memory |
- 6 x 184-pin DIMM sockets
- Each DIMM socket supports 128MB to 2GB PC2100 DDR registered DIMM module
- Supports ECC-based 128MB to 12GB memory capacity |
Slots |
- 2 x 32bit/33MHz/5V PCI slot
- 4 x 64bit/100MHz/3V PCI-X slots |
Onboard I/O |
- 1 x PS/2 keyboard port, 1 x PS/2 mouse port
- 1 x Floppy port (Up to 2.88MB, 3 Mode)
- 2 x ATA100 IDE connectors
- 2 x External USB ports (Support Hot-Plug Function)
- 1 x External serial port
- 1 x Parallel port (ECP, EPP Port)
- 1 x VGA port
- 2 x RJ-45 LAN ports /w LED
- 2 x Feature connectors (for IPMI solution) |
Onboard LAN |
- 1 x Intel 82544 PCI-X Gigabit Ethernet controller
- 1 x Intel 82540 32bit PCI Gigabit Ethernet controller
- Supports 10/100/1000 Mbps transfer rates |
Onboard IDE |
- Dual channel bus master IDE ports support ATA100, Multi-Word DMA Mode 2, PIO Mode 3/4
- ATAPI IDE CD-ROM, CD-R, CD-RW and ZIP LS-120 supported |
PC Health Monitoring |
PC Health Monitoring Chip Supports the following:
- FAN sensor & control x3: CPU fan*2, chassis fan*1
- Voltage sensor : Vcore, +2.5V, +3V, +5V, +12V,+3VSB, VBAT
- 3xThermal sensor: Environment x 1, CPU x 2 (CPU sensor use internal thermal diode) |
Front and Back Panel |
- Front panel: 20-pin PANEL, 2-pin HDD LED
- Supports power button, reset button, speaker, LAN activity LED, system warning/failure LED, chassis intrusion switch, HDD access LED, NMI button, power status LED, front panel LED
- Back panel: PS/2 keyboard & mouse, USB x2 , serial x2, parallel x1 , LAN x1, VGA x1 |
Onboard Connector |
- 3V, 5V, and 12V 24-pin ATX Power Connector
- 12V 4-pin power connector
- FAN: CPU ,chassis connectors
- 8-pin DIP Switch: clear PASSWD,configure CMOS
- 2 x 40-pin IDE connector
- 1 x 34-pin floppy connector |
BIOS |
- 4Mbit Flash memory
- Award BIOS with ACPI, DMI, Green, PnP features, plus Enhanced Server BIOS features, VGA BIOS |
Special Feature |
Throttling mode support (System will automatically speed down while CPU is overheat.) |
Board Size |
ATX (12"x 13") |
|
North Bridge: Intel E7501
